Electrical data
Input voltage AC 198…264 V
Nominal voltage 220…240 V
Mains frequency 50…60 Hz
DC voltage 176…276 V
Working frequency 40…50 kHz
Maximum number of ECGs on a z 10 A (B) 8
Maximum number of ECGs on a z 16 A (B) 13
Inrush current 57 A
Lighting technical data
Start-up time 1.5 s
Dimensions
Length 360.0 mm
Width 30.0 mm
Height 21.0 mm
Mounting hole distance, length 350.0 mm
Product weight 239.90 g
Temperatures and operating conditions
Ambient temperature range -20…+50 °C
Permissible relative humidity 5…85 %
Lifetime E-VSA 100000 h
Power Suitable for luminaires with safety class I / II
End of Life Safety Shutdown EOL T.2
Certificates & Standards
Approvals EL / VDE / ENEC 10 / VDE-EMC
EEI – Energy label A2 BAT
Standards Acc. to IEC 61347-2-3 / App. J/According to EN 55015:2006 + A1:2007 + A2:2009/According to EN 61000-3-2/According to EN 61547
