Product Features
These lamps work in conjunction with a ballast,
As a result, the various assets can not be exchanged.
Nominal power | 1000.00 W |
Nominal power | 960.00 W |
Lampstroom | 10.6 A |
Rated voltage | 110 V |
Ignition voltage | 3.6 / 5.0 kVp |
Lamb performance (standard situation) | 135 lm / W |
Photometric data
Light current | 130000 lm |
Color view index Ra | ≤25 |
Color temperature | 2000 K |
Light current (LLMF) at 2,000 h | 0.96 |
Light current (LLMF) at 4000 h | 0.93 |
Light current (LLMF) at 6,000 h | 0.91 |
Light current (LLMF) at 8,000 h | 0.89 |
Light current (LLMF) at 12,000 h | 0.84 |
Light current (LLMF) at 16,000 h | 0.81 |
Light current (LLMF) at 20,000 h | 0.79 |
Dimensions
Diameter | 66.0 mm |
Length | 360.0 mm |
Distance a / LCL | 240.0 mm |
Product weight | 300.00 g |
Temperatures and operating conditions
Max. permitted outdoor flask temp. | 400 ° C |
Max. allowed fitting edge temp. | 250 ° C |
Lifetime
Functioning lamps at 2,000 h | 0.99 |
Functioning lamps at 4000 h | 0.98 |
Functioning lamps at 8,000 h | 0.95 |
Functioning lamps at 12,000 h | 0.87 |
Functioning lamps at 16,000 h | 0.74 |
Functioning lamps at 20,000 h | 0.50 |
Lifetime B50 | 20000 h |
Lifetime B10 | 11000 h |
Lifetime B5 | 8000 h |
Additional product data
Lamp cap | E40 |
Product comment | ErP compliant according to EU Regulation 245/2009 |
Shape / Performance | Bright |
Mercury content | 39.0 mg |
Power
Dimmable | Yes |
Fire condition | Random |
Closed luminaire required | No |
Certificates & Standards
Energy efficiency class | A ++ |
