| Cap-Base |
E27 [E27]
|
| Operating Position |
UNIVERSAL [Any or Universal (U)]
|
| Life To 5% Failures (Nom) |
12000 h
|
| Life To 20% Failures (Nom) |
22000 h
|
| Life To 50% Failures (Nom) |
28000 h
|
| System Description |
External Ignitor
|
| LSF 2000 h Rated |
99%
|
| LSF 4000 h Rated |
99%
|
| LSF 6000 h Rated |
99%
|
| LSF 8000 h Rated |
98%
|
| LSF 12000 h Rated |
94%
|
| LSF 16000 h Rated |
86%
|
| LSF 20000 h Rated |
76%
|
| Color Code |
220 [CCT or 2000K]
|
| Luminous Flux (Rated) (Min) |
4500 lm
|
| Luminous Flux (Rated) (Nom) |
5600 lm
|
| Lumen Maintenance 10000 h (Nom) |
85%
|
| Lumen Maintenance 2000 h (Min) |
85%
|
| Lumen Maintenance 2000 h (Nom) |
93%
|
| Lumen Maintenance 5000 h (Min) |
80%
|
| Lumen Maintenance 5000 h (Nom) |
88%
|
| Correlated Color Temperature (Nom) |
2000 K
|
| Luminous Efficacy (rated) (Nom) |
80 lm / W
|
| Color Rendering Index (Max) |
25
|
| Color Rendering Index (Nom) |
-
|
| LLMF 2000 h Rated |
93%
|
| LLMF 4000 h Rated |
89%
|
| LLMF 6000 h Rated |
86%
|
| LLMF 8000 h Rated |
84%
|
| LLMF 12000 h Rated |
81%
|
| LLMF 16000 h Rated |
79%
|
| LLMF 20000 h Rated |
78%
|
| Power (Rated) (Nom) |
70.0 W
|
| Lamp Current (EM) (Nom) |
0.98 A
|
| Ignition Supply Voltage (Max) |
198 V
|
| Ignition Peak Voltage (Max) |
1800 V
|
| Re-Ignition Time (Min) (Max) |
180 s
|
| Ignition Time (Max) |
5 s
|
| Voltage (Max) |
105 V
|
| Voltage (Min) |
75 V
|
| Voltage (Nom) |
90 V
|
| Dimmable |
Yes
|
| Run-Up Time 90% (Max) |
5 min
|
| Bulb Finish |
Coated glass
|
| Energy Efficiency Label (EEL) |
a
|
| Mercury (Hg) Content (Nom) |
16.3 mg
|
| Energy Consumption kWh / 1000 h |
77 kWh
|
| Bulb Temperature (Max) |
350 ° C
|
| Cap-Base Temperature (Max) |
200 ° C
|
| Full product code |
871150021024130
|
| Order product name |
SON 70W E E27 CO 1CT / 24
|
| EAN / UPC - Product |
8711500210241
|
| Order code |
928486700091
|
| Numerator - Quantity Per Pack |
1
|
| Numerator - Packs per outer box |
24
|
| Material Nr. (12NC) |
928486700091
|
| Net Weight (Piece) |
0.059 kg
|
